Description:
The stirred tilting jacketed kettle, built upon the foundation of the vertical jacketed kettle, incorporates stirring and tilting functionalities, significantly enhancing the equipment’s versatility and application scope. Many food products with high concentrations are prone to bottom burning during heating in the kettle, which can adversely affect the appearance, taste and even safety of the food production process. in such cases, the inclusion of a stirring function in the jacketed kettle becomes crucial. The Tiltable design facilitates the smooth removal ot finished products from the kettle after food processing,making it a simple yet highly practical design.
Advantages:
Temperature Control: The electric heating jacketed kettle precisely regulates processing temperature via thermal oil in the jacket. Even, linear heating extends the pot's lifespan.
Safety: Auto-cutoff when exceeding set temperatures—prevents both ingredient damage and safety hazards.
Material Thickness: 4mm inner + 3mm outer wall construction for extreme durability.
Pot: Spun, one-piece 304 stainless steel casting. Non-stick, scorch-resistant design ensures food safety and reduces waste.
Custom Options: Adjustable mixing speed (no extra cost), add-ins like insulation layers, frequency converters, or wireless temperature control.
Technical parameters：
|
Volume |
diameter |
depth |
breadth |
height |
weight |
motor power |
Heating power |
|
100L |
720mm |
480mm |
1120mm |
1480mm |
160kg |
0.75kw |
12kw |
|
200L |
860mm |
540mm |
1250mm |
1520mm |
190kg |
1.1kw |
24kw |
|
300L |
950mm |
600mm |
1300mm |
1580mm |
220kg |
1.1kw |
36kw |
|
400L |
1030mm |
660mm |
1350mm |
1650mm |
260kg |
1.5kw |
36kw |
|
500L |
1120mm |
720mm |
1420mm |
1700mm |
300kg |
2.2kw |
48kw |
|
600L |
1200mm |
780mm |
1500mm |
1750mm |
350kg |
2.2kw |
48kw |
