Description:
The UHT (Ultra-High Temperature) Instant Sterilizer is widely used for the sterilization of milk, fruit juice, tea beverages, and other products. This ultra-high temperature sterilizer integrates heating, sterilization, cooling, and heat recovery into one system. A touch screen displays real-time production data online. This equipment is suitable for continuous sterilization of fruit and vegetable juice, tea beverages, dairy drinks, or similar materials. It enables ultra-high temperature instant sterilization and rapid pasteurization within a short period, ensuring that the nutrients in the material are not destroyed or lost, and the product color remains unchanged.
Advantages:
All food-contact pipes are made of 316 stainless steel, ensuring long service life.
Four-stage plate heat exchanger with excellent heat transfer and precise temperature control. (Plate type)
All electronic components are from top international brands; the PLC program is easy to operate and offers strong control capabilities.
Professional installation and operation guidance videos are provided entirely in English, allowing self-installation without on-site support.
With rich experience, we can customize sterilization programs for various products with adjustable temperatures.
High degree of automated cleaning with minimal residue, ensuring food safety and hygiene.
Pipes are arranged densely for high throughput, high heat exchange efficiency, and energy savings.
Technical parameters：
|
Processing capacity (T/H) |
Using steam pressure (Mpa) |
High-temperature heating duration (S) |
Weight(KG) |
Dimensions（mm） |
Steam consumption (KG/L) |
Power (KW) |
|
0.5 - 1 |
≤0.4 |
6 - 8 |
280 |
1200*920*1650 |
0.12 |
2.2 |
|
1 - 2 |
≤0.4 |
6 - 8 |
380 |
1300*1100*1700 |
0.15 |
2.2 |
|
3 - 4 |
≤0.4 |
6 - 8 |
550 |
1600*1200*1800 |
0.2 |
3 |
|
5 - 6 |
≤0.4 |
6 - 8 |
700 |
1940*1400*2000 |
0.3 |
4 |
