Description：
The high shear tank, through its efficient mixing, emulsifying, and homogenizing functions, quickly and uniformly blends different ingredients, significantly enhancing product consistency and stability, reducing layering and sedimentation, while saving production time and costs. Its powerful processing capability allows it to handle various types of materials, meeting diverse production needs.
Advantages:
Polishing Standard
Seamless internal mirror polish (Ra≤0.4μm) eliminates material adhesion and bacterial growth
Material Specifications
Triple-layer tank construction:
3mm (inner) + 2mm (structural) + 1.5mm (outer) 304L stainless steel
Exceeds industry durability standards by 40%
Engineering Advantages
100mm polyurethane insulation reduces thermal loss by 35%
Integrated safety systems:
Sight glasses with CIP cleaning ports
Pressure-balanced venting channels
Technical Support
Modular design ensures cross-equipment compatibility
Plug-and-play installation with:
Dedicated process engineers
Customized FAT protocols
Mixing Performance
2,800 RPM direct-drive motor (IE4 efficiency class)
Optional variable frequency drive (0-100% stepless adjustment)
Universal adapters for viscous/non-Newtonian fluids
Technical Parameters:
|
Capacity(L) |
Power(KW) |
Size（mm） |
material quality |
thermal insulating property |
Rotation speed |
|
150 |
2.2KW |
760*1020*1600mm |
SUS304 |
≤ 1°C /3H |
900-5000RPM |
|
200 |
3KW |
820*1220*1650mm |
SUS304 |
≤ 1°C /3H |
900-5000RPM |
|
300 |
4KW |
880*1280*1650mm |
SUS304 |
≤ 1°C /3H |
900-5000RPM |
|
500 |
5.5KW |
950*1350*1900mm |
SUS304 |
≤ 1°C /3H |
900-5000RPM |
|
1000 |
/ |
1070*1400*1900mm |
SUS304 |
≤ 1°C /3H |
900-5000RPM |
|
2000 |
/ |
1550*1900*2450mm |
SUS304 |
≤ 1°C /3H |
900-5000RPM |
