Description:
Continuous vacuum packaging machine, also known as chain driven vacuum packaging machine, is a kind of packaging equipment that uses chain drive to work continuously. When the machine works, it will automatically cover for vacuum and sealing, and the vacuum cover will automatically pop up to output products, eliminating the need for manual lifting, capping and product storage process of double chamber vacuum packaging machine.
Advantages:
Easy to Operate: Simple structure, cost-effective, one-button operation, and low maintenance costs.
Wide Application: Sealing lengths of up to 1 meter or more, suitable for processing bags of various sizes.
High Efficiency: Roller conveyor worktable reduces unloading time after processing, significantly increasing packaging speed.
Technical parameters：
Model |
YF-1000 (Single Sealing Strip) |
YF-1100 (Double Sealing Strip) |
Power supply |
3000W |
|
Machine weight |
730KG |
|
Voltage |
380V/50HZ(Can Customize) |
|
Pump Rate |
100L/200L Optional |
|
Sealing size |
1000*10mm |
|
Sealing strip distance |
420mm |
|
Packaging ability |
2-5Times/Min |
|
Vacuum chamber size |
1125*440*100mm |
|
Max package size |
1000*420*9mm |
1000*210*9mm |
Machine size |
2020*1620*1200mm |
|
